Additional information
| Weight | 20,975 kg |
|---|---|
| Reference number | A 457 130 7215, A4571307215 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 14.3562 |
| Cooling | Water |
| Crankshaft thread | M20 x 1.5 LH |
| Important information | When replacing this compressor a new flange gasket is required. Flange gasket 9121101404 to be bought separately |
| Lubrication | Lubrication supplied from engine |
| Max. operating pressure | 181.3 psi |
| Mounting | Mounting Flange |
| Operating speed | 3000 (1/min) |
| Piston diameter | 3.35 in |
| Piston stroke | 2.20 in |
| Port thread 0 | M30 x 1.5 |
| Port thread 2 | M26 x 1.5 |
| Port thread 21 | M26 x 1.5 |
| Port thread 22 | M26 x 1.5 (closed) |
| Port thread 4 | M12 x 1.5 |
| Port thread 8.1 | Ø 0.16 in |
| Port thread 9 | M12 x 1.5 |
| Port thread 9.1 | M16 x 1.5 |
| Port thread 9.2 | M16 x 1.5 |
| Swept volume (cm³) | 636 cm<sup>3</sup> |
| Technical specification | OE specification |
| Type | Twin Cylinder |
| GTIN | 7895851080546 |
| Size (mm x mm x mm) | 232 x 280 x 221 |
| UPC | 193133344650 |
| Weight (kg) | 20.975 |
| Weight (lb) | 46.2419 |
| Port thread 8.2 | Ø 15.5 mm |
| Brand | WABCO |
