Additional information
| Weight | 1,644 kg |
|---|---|
| Reference number | 81521616341, 81521616342, 81521616347, 81521619342, 81521616342, 81521616342 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuation angle | -45° to +30° |
| Break point | 8.7 psi |
| Calculated Volume (dm³) | 4.485 |
| Distance between bolts | 3.31×3.31 in |
| Exhaust | Snap-on contour |
| Max. operating pressure | 145.0 psi |
| Mounting | 4x M8 |
| Port thread 1 | M16 x 1.5 |
| Port thread 2 | M16 x 1.5 |
| Port thread 4 | M16 x 1.5 |
| Regulating ratio | 1:8 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Mechanical |
| Type of operation | Relay Valve |
| GTIN | 04057875224549 |
| UPC | 193133483601 |
| Weight (kg) | 1.644 |
| Weight (lb) | 3.6244 |
| Size (mm x mm x mm) | 150 x 130 x 230 |
| Brand | WABCO |
