Additional information
| Weight | 20,083 kg |
|---|---|
| Reference number | TDAS9125420070, S9125420070, S9125420070XRMAN, 22062021, 8235-S9125420070, 85013937, 6300-912542007R, S9125420070, S9125420070X, S9125420070XRMAN, TDAS9125420070X, WAB912542007R |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 21.9523 |
| Cooling | Water |
| Crankshaft thread | M20 x 1.5 |
| Lubrication | Lubrication supplied from engine |
| Max. operating pressure | 203.1 psi |
| Mounting | Mounting Flange |
| Operating speed | 3000 (1/min) |
| Piston diameter | 3.35 in |
| Piston stroke | 2.20 in |
| Port thread 0 | 1.37 in |
| Port thread 2 | M26 x 1.5 |
| Port thread 4 | M16 x 1.5 |
| Port thread 8.1 | M12 x 1.5 |
| Port thread 9.1 | M16 x 1.5 |
| Port thread 9.2 | M16 x 1.5 |
| Stroke | 56.0 mm |
| Technical specification | OE specification |
| Type | Twin Cylinder |
| GTIN | 04057875274995 |
| Size (mm x mm x mm) | 368 x 319 x 187 |
| UPC | 193133447627 |
| Weight (kg) | 20.083 |
| Weight (lb) | 44.2754 |
| Swept volume (cm³) | 636 cm<sup>3</sup> |
| Brand | WABCO |
