Additional information
| Weight | 8,316 kg |
|---|---|
| Reference number | 0174207718, A0174207718 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | 2 x M16 x 1.5 |
| Calculated Volume (dm³) | 12 |
| Cooling | Air |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 145.04 / 116.03 psi |
| Nominal diameter | 8.5 mm |
| Output force | 1294.90 lbf |
| Output force 3 | 1294.90 lbf |
| Port thread 11 | M16 x 1.5 |
| Port thread 12 | M16 x 1.5 |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Release pressure | 66.72 psi |
| Return-spring force | 33.72 lbf |
| Stroke | 2.24 / 2.24 in |
| Temperature range | -40°C to +80°C |
| Total lenght | 10.24 in |
| Type | 12/16 |
| Type of operation | Disc |
| Version | Without boot |
| Yoke | No |
| GTIN | 7895851019324 |
| Size (mm x mm x mm) | 375 x 185 x 173 |
| UPC | 193133348351 |
| Weight (kg) | 8.316 |
| Weight (lb) | 18.33 |
| Technical specification | OE specification |
| Brand | WABCO |
