Trailer Lift Axle Control Valve

399,00

Trailer Lift Axle Control Valve

Electric Actuation.

Dual – Circuit

With Test – Port

Compleet with pipes and connection parts

In stock

excl. VAT € 482,79 incl. VAT
Category: SKU: WAB4630840100

Description

Trailer Lift Axle Control Valve

Electric Actuation.

Dual – Circuit

With Test – Port

Compleet with pipes and connection parts

  • Brand – WABCO Original
  • Part type – Premium original quality
  • Product category – Device
  • Actuation – Electrical
  • Application – Trailer
  • Bolt lengths – 0.47 in
  • Calculated Volume (dm³) – 2.607
  • Electrical connection – M27 x 1
  • Max. operating pressure – 188.5 psi
  • Port thread 1 – M16 x 1.5
  • Port thread 2 – M22 x 1.5
  • Port thread 21 – M16 x 1.5
  • Port thread 22 – M16 x 1.5
  • Port thread 23 – M16 x 1.5
  • Port thread 24 – M16 x 1.5
  • Port thread 3 – Flap Exhaust
  • Port thread 41 – M16 x 1.5
  • Port thread 42 – Test port
  • Protection class – IP 6K6K
  • Rated current – 220 mA
  • Technical specification – OE specification
  • Temperature range – -40°C to +80°C
  • Type – LACV
  • Version – Dual-circuit
  • Voltage – 24 V
  • Size (mm x mm x mm) – 146 x 166 x 129
  • UPC – 193133305897
  • Weight (kg) – 2.2
  • Weight (lb) – 4.8502
Part NumberManufacturerCross Reference
4630840100DAEWOO3425600040
4630840100DAEWOOP34256 00040
4630840100DAF867871
4630840100DAF0867871
4630840100DAF867868
4630840100DOLL7087042
4630840100FAYMONVILLE6168
4630840100FAYMONVILLE06168
4630840100FELDBINDER007473
4630840100GOLDHOFER164279
4630840100HENDRICKSON4630840100
4630840100KEMPF1133001
4630840100KRONE5815506
4630840100KRONE58155060
4630840100KÖGEL339950
4630840100LANGENDORF1111151
4630840100NIPPON TREX910015-00019
4630840100NOOTEBOOM1098567
4630840100NOOTEBOOM088255
4630840100PACCAR0867871
4630840100SCANIA1738470
4630840100SCHMITZ CARGOBULL051267
4630840100SCHMITZ CARGOBULL51267
4630840100SCHWARZMÜLLER39514
4630840100SHOWA AIRCRAFTA8188-012100
4630840100Tirsan21153104020
4630840100VAN HOOL10573143
4630840100VOLVOWA4630840100
4630840100ZORZI1013155

Additional information

Weight2,3420 kg
BrandWABCO
Model

2 – circuit

Properties

Complete

Reference number

0867871, 0911802, 2280106, 3548 018 002 0, 35480180020, 400 602 261 0, 4006022610, 4006022610WAB, 463 084 010 0, 463 084 011 0, 4630840100, 4630840100WAB, 4630840110, 4630840110WAB, COJ2280106, SOR35480180020, WAB4006022610, WAB4630840100, WAB4630840110

Reviews

There are no reviews yet.

Be the first to review “Trailer Lift Axle Control Valve”
WAB4630840100.pdf Map1.pdf
