Additional information
| Weight | 9,53 kg |
|---|---|
| Reference number | A9584202818 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 16.554 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Output force M | 2293.05 lbf |
| Port thread 11 | M22 x 1.5 JED – 388 |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Release pressure | 98.63 psi |
| Return-spring force | 53.95 lbf |
| Stroke | 2.52 / 2.52 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 11.50 in |
| Type | 20/24 HFL3 |
| GTIN | 04057875282600 |
| Size (mm x mm x mm) | 191 x 214 x 405 |
| UPC | 193133414100 |
| Weight (kg) | 9.53 |
| Weight (lb) | 21.01 |
| Type of operation | Disc |
| Brand | WABCO |
