Additional information
| Weight | 2,022 kg |
|---|---|
| Reference number | 3454403440, 34544 03440, P34544 03440, 1315686, 0054296944, 0375215, 361623, 41032230, A0054296944, A0054291244, A0044298644, 1612935610102, 446000096A, 595107M000, 59510 7M000, 41032230, 8015516, 41032230, 0054296944, 0375215, 361623, 1315686, F00282560, N1011063689, 0054291244, 0054296944, A0054291244, A0054296944, 0044298644, A0044298644, 0375215, 361623, 41032230, 16H1208526AA, 1505280, 1505288, 1935135, 96643, 1102304000, 920924011, 20297660, 759010011 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Application | Norm |
| Calculated Volume (dm³) | 3.2675 |
| Distance between bolts | 3.94×2.52 in |
| Electrical connection | Bayonet (DIN 72585) |
| Max. operating pressure | 147.94 psi |
| Mounting | 3x M8 |
| Port thread 1 | M22 x 1.5 JED-388-4 |
| Port thread 21 | M22 x 1.5 JED – 388-4 |
| Port thread 22 | M22 x 1.5 JED – 388-4 |
| Port thread 3 | Silencer |
| Port thread 4 | M16 x 1.5 JED – 388-4 |
| Protection class | IP 6K6K / IP 6K9K |
| Rated current | 1400 mA |
| Silencer | 4324070500 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Voltage | 24 V |
| GTIN | 7895851044159 |
| Size (mm x mm x mm) | 161 x 123 x 165 |
| UPC | 193133487807 |
| Weight (kg) | 2.022 |
| Weight (lb) | 4.4577 |
| Thread | Voss 232 |
| Brand | WABCO |
