Additional information
| Weight | 2,013 kg |
|---|---|
| Reference number | T101913, 577677, 583512, 1518893, A0014315205, 385880020060, F385880020060, TDAS4712001100, 03420702, 03435116, S471-200-110-0, 1111569, 5029664, 502966408, S4712001100, 6300-4712001100, 81523016028, 81523016044, 81523016141, 81523016169, 88521806204, 88523016204, 0014310705, 0014314605, 0014315205, A0014315205, S4712001100, S471-200-110-0, 5000242207, 7700051794B, 7700051794, WAB4712001100, 348486 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 4.0435 |
| Distance between bolts | 4.61×4.61 in |
| Max. operating pressure | 116.0 psi |
| Mounting | 4x M10 |
| Port thread 1 | M22 x 1.5 |
| Port thread 2 | M22 x 1.5 |
| Port thread 4 | M22 x 1.5 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Version | 1 Circuit |
| GTIN | 04057875217466 |
| Size (mm x mm x mm) | 195 x 144 x 144 |
| UPC | 193133442929 |
| Weight (kg) | 2.013 |
| Weight (lb) | 4.4379 |
| Brand | WABCO |
