Additional information
| Weight | 1,81 kg |
|---|---|
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 4.244 |
| Distance between holes | 2.23×2.23 inch |
| Electrical connection | DIN 72585-A1-3.6-Sn/K2 |
| Handle length | 4.8 inch |
| Max. operating pressure | 145.0 psi |
| Mounting | 4× M8 |
| Port thread 1 | Ø 8 x 1 |
| Port thread 21 | Ø 8 x 1 |
| Port thread 22 | Ø 8 x 1 |
| Port thread 23 | Ø 8 x 1 |
| Port thread 24 | Ø 8 x 1 |
| Protection class | IP 6K9K |
| Rated current | 0.34 A |
| System | Standard |
| Technical specification | OE specification |
| Temperature range | -40 to +65 °C |
| Voltage | 12 V |
| GTIN | 04057885108211 |
| Size (mm x mm x mm) | 186 x 92 x 248 |
| UPC | 193133501817 |
| Weight (kg) | 1.81 |
| Weight (lb) | 3.99 |
| Type | 2-circuit |
| Brand | WABCO |
