Additional information
| Weight | 9,56 kg |
|---|---|
| Reference number | 1506681, 1519442, 1524581, 1530832, 1530833, A0204203318, A0204203418, A0204203518, A0204203618, 0154207518, 0154207618, 0154208518, 0154208618, 0204204918, 0204205018, A0154208618, A0204204918, A0204205018, A0214209718, A0214209818, 1524581, 542529, 542530, 2131116 |
| Brand | ProVia |
| Part type | Reliable spare parts |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 17.22 |
| Connection port / fitting | M22×1.5/VOSS 232 |
| Connection specification | JED-388-3 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 145.04 / 123.28 psi |
| Output force service brake | 7.7 kN |
| Output force spring brake | 5.5-10 kN |
| Port thread 11 | M22 X 1.5 |
| Port: working pressure [p emax.] | <strong>11</strong>: 10 bar (13 bar), <span><strong>12</strong>: 8.5 bar (11 bar)</span> |
| ProVia warranty | 1 year |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Release pressure | 71.07 psi |
| Return-spring force | 49.46 lbf |
| Technical specification | AM specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 11.26 in |
| Type | 20/24 |
| Type of operation | Disc |
| GTIN | 04057877001919 |
| Size (mm x mm x mm) | 400 x 210 x 205 |
| UPC | 193134005369 |
| Weight (kg) | 9.56 |
| Weight (lb) | 21.08 |
| Stroke | 2.56 / 2.56 in |
| Brand | WABCO |
