Additional information
| Weight | 0,605 kg |
|---|---|
| Reference number | 99707005852, 1612935610115, 8015518, 41025617, 235600130, EXABRD673, 3121232, 16H1208502AA, 2089747, 1045507, DZ95189584040, 1102305010, 11167594, 759010018, 20330057 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.35632 |
| Electrical connection | Bayonet DIN 72 585 A1-2.1-Sn/K2 |
| Exhaust | 4.0 mm |
| Max. operating pressure | 188.5 psi |
| Multi Nominal diameter (From Port 1 to x) | 0.16 in |
| Nominal diameter | 4.0 mm |
| Port thread 1 | V12 x 1.5 |
| Port thread 2 | M12 x 1.5 |
| Port thread 3 | M12 x 1.5 |
| Port threads | M12 x 1.5 |
| Protection class | IP 6K9K / IP 6K7 |
| Rated current | 690 mA |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Normally open |
| Voltage | 24 V |
| Size (mm x mm x mm) | 40 x 131 x 68 |
| UPC | 193133311331 |
| Weight (kg) | 0.605 |
| Weight (lb) | 1.33 |
| GTIN | 04057875218487 |
| Brand | WABCO |
