Additional information
| Weight | 0,034 kg |
|---|---|
| Reference number | 662200, 617568, M80002901, 3425002900, 34250 02900, P34250 02900, 1783123, 1450872, 1652528, 7069647, 168717, H0356D05001A0, M800029, M80002901, 559707K701, 55970 7K701, 58250 UA641, 504255336, 41200718, 504103341, 0055425818, 41200703, 98472891, S4410441020, 515015646, 505810540, 5058105400N, 3483130, 348313, 4300630, ABRD757, 10168214, A05101320, A05101477, 6300-4410441020, 0055425818, 41200703, 41200718, 504103341, 504255336, 98472891, S4410441020, 223659X401, 22365LA30A, 1243506, 158592, 16068, 1783123, S4410441020, 5010143099, 1934575, 1075291, S053406, 66125, DZ95189583035, 223659X401, 22365LA30A, 11110063, 11213114, 759001019, 41159322, WA4410441020, WAB4410441020, 355000549, 1013170 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.04524 |
| Electrical connection | Bayonet DIN 72585 A1-3.1-Sn/K2 |
| Hysteresis | 0.2% FS |
| Linearity | 0.3% FS |
| Max. operating pressure | 232.1 psi |
| Measuring range | 0 to 145 Psi |
| Port thread 0 | M16 x 1.5 |
| Port threads | M16 x 1.5 |
| Predominance | 0.5 V |
| Protection class | IP6K7/IP6K9K |
| Rated current | 15 mA |
| Sealing | 8977702504 |
| Sensitivity | 0.40 V/bar |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Piezo-Resistive |
| Voltage | 24 V |
| GTIN | 7895851055193 |
| Size (mm x mm x mm) | 52 x 30 x 29 |
| UPC | 193133438991 |
| Weight (kg) | 0.034 |
| Weight (lb) | 0.074957 |
| Version | With sealing |
| Brand | WABCO |
