Additional information
| Weight | 3,341 kg |
|---|---|
| Reference number | 659764, 1524016, S351401076Z, 1612135500007, W20705.04000.01W, S4613186040, 35XG114020, 235434550, 35XG1-14020, 6300-4613186040, S4613186040, 1524016, S4613186040, 6127GC3514010, AZ87351400102, 1102408300, 70313310, 70313349, 1698699, 70301712, 85101418, 9958670, WAB4613186040, 351400042 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuation | 4619017831 |
| Basic valve | 4613150731 |
| Calculated Volume (dm³) | 11.6579 |
| Distance between holes | 3.15×7.09 in |
| Electrical connection | Bayonet plug 4-pin |
| Exhaust | Snap-on contour |
| Max. operating pressure | 145.0 psi |
| Mounting | 3x Ø 9.5 mm |
| Pedal angle | 43° |
| Port thread 11 | M16 x 1.5 |
| Port thread 12 | M16 x 1.5 |
| Port thread 21 | M16 x 1.5 |
| Port thread 22 | M16 x 1.5 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| GTIN | 04057875210160 |
| UPC | 193133442257 |
| Weight (kg) | 3.341 |
| Weight (lb) | 7.3656 |
| Size (mm x mm x mm) | 282 x 390 x 106 |
| Brand | WABCO |
