Additional information
| Weight | 8,12 kg |
|---|---|
| Reference number | 20522031, 20466072, 2052203 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 13.566 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Opposite | 925 481 030 0 |
| Output force M | 1933.36 lbf |
| Port thread 11 | M16 x 1.5 JED – 464-0 |
| Port threads | M16 x 1.5 |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Release pressure | 76.87 psi |
| Return-spring force | 55.08 lbf |
| Stroke | 2.56 / 2.52 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | 24/24 IBV |
| Type of operation | Disc |
| GTIN | 04057875282921 |
| Size (mm x mm x mm) | 340 x 210 x 190 |
| UPC | 193133354369 |
| Weight (kg) | 8.12 |
| Weight (lb) | 17.902 |
| Total lenght | 10.16 in |
| Brand | WABCO |
