Additional information
| Weight | 2,056 kg |
|---|---|
| Reference number | 1337007, 1443520, 1443521, 1241256, 1340024, 1346866, 286295 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 5.726 |
| Distance between holes | 4.33 in |
| Important information | Please follow the installation instructions of the vehicle manufacturer |
| Length | 373 mm |
| Max. operating pressure | 145.0 psi |
| Medium | Brake fluid SAE J 1703 |
| Mounting | 4x Ø 9.0 mm |
| Port thread 1-4 | M14 x 1.5 |
| Port thread 11 | M16 x 1.5 JED – 464 |
| Port thread 31 | Flap Exhaust |
| Port thread 32 | Ø 8.0 mm |
| Push-rod thread | Ball Ø 12.0 mm |
| Stroke | 3.35 in |
| Technical specification | OE specification |
| Temperature range | -30°C to +100°C |
| GTIN | 04057875300809 |
| UPC | 193133374329 |
| Weight (kg) | 2.056 |
| Weight (lb) | 4.5327 |
| Size (mm x mm x mm) | 411 x 108 x 129 |
| Brand | WABCO |
