Additional information
| Weight | 3,005 kg |
|---|---|
| Reference number | 445332068, 1505241, A0064205224, 13844, 007912, AJV4526, 169345, 4231047100, 2001036, 2001001, 58128660, 5812866, 5058128660, 505812866, 334652, 4110711, 0064205224, A0064205224, 1815504, 14338, 1505241, 4454106560, 4454108160, 3454106560, 3454108160, 1932621, 50397001, WA4231047100 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 3.58 |
| Clamp band | 166 mm |
| Clamp band position | 20° |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 psi |
| Operating pressure | 147.9 psi |
| Output force | 1820.95 lbf |
| Output force M | 1820.95 lbf |
| Port (side) | M16 x 1.5 |
| Port (top) | M16 x 1.5 |
| Port angle | 0° |
| Port threads | M16 x 1.5 |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Stroke | 2.24 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 4.17 in |
| Type | 16 |
| Type of operation | Disc |
| Version | Without boot |
| GTIN | 04057875162698 |
| Size (mm x mm x mm) | 142 x 184 x 137 |
| UPC | 193133245896 |
| Weight (kg) | 3.005 |
| Weight (lb) | 6.6249 |
| Return-spring force | 49.46 lbf |
| Brand | WABCO |
