Additional information
| Weight | 1,608 kg |
|---|---|
| Reference number | 81521616373, 81521616374, 81521616375, 81521616376, 81521619373, 81521616373 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 0.79 in |
| Break point | 8.7 psi |
| Calculated Volume (dm³) | 4.0329 |
| Control Pressure | Max 145 psi |
| Control stroke | 0° to +60° |
| Cooling | Air |
| Distance between bolts | 3.31×3.31 in |
| Exhaust | Snap-on contour |
| Max. operating pressure | 188.5 psi |
| Mounting | 4x M8 |
| Port thread 1 | M22 x 1.5 JED-388 |
| Port thread 2 | M22 x 1.5 JED – 152 |
| Port thread 4 | M16 x 1.5 JED – 388 |
| Port threads | M22 x 1.5 |
| Regulating ratio | 1:8 |
| Technical specification | OE specification |
| Total stroke | -30° to +110° |
| Type | Mechanical |
| Type of operation | Dynamic |
| GTIN | 04057875224099 |
| Size (mm x mm x mm) | 227 x 141 x 126 |
| UPC | 193133483298 |
| Weight (kg) | 1.608 |
| Weight (lb) | 3.545 |
| Temperature range | -40°C to +80°C |
| Brand | WABCO |
