Additional information
| Weight | 3,081 kg |
|---|---|
| Reference number | 4321059000, 605109100, 0834482, 834482, A6994200724, A6984203721, 0941, 006677, ASX0014019, 200260, NB1759, 3345107R1, 34140, 00034140, 2001006, 945154, 50945154, 175202, 79302, 1109374, 834482, BBU5931, 502918601, A05010104, 81511016076, 81511016077, 81511016078, 81511016079, 81511016199, 81511019076, 0024206518, 6994200724, 6984203721, A6984203721, A6994200724, A6994203721, 6994203721, S4231059000, 07010020, 305050, 0834482, 5021170049, 4454112600, 1738479, 051009, 1020753, 3551, 3345107R1, 99000360485, 526031200000, BBU5931, WA4231059000 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.36 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 9.8 |
| Clamp band | 174 mm |
| Clamp band position | -45° |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 123.28 psi |
| Operating pressure | 123.3 psi |
| Output force | 1843.43 lbf |
| Output force M | 1843.43 lbf |
| Port (side) | M16 x 1.5 JED-152 |
| Port (top) | M16 x 1.5 JED-152 |
| Port angle | 180° |
| Port threads | M16 x 1.5 |
| Push-rod length | 7.32 in |
| Push-rod thread | M16 x 1.5 |
| Stroke | 2.95 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Thread length | 7.32 in |
| Total lenght | 5.28 in |
| Type | 20 |
| Type of operation | Cam |
| Version | Without boot |
| Yoke | Without |
| GTIN | 04057875163251 |
| Size (mm x mm x mm) | 175 x 175 x 320 |
| UPC | 193133422808 |
| Weight (kg) | 3.081 |
| Weight (lb) | 6.7924 |
| Return-spring force | 22.48 lbf |
| Brand | WABCO |
