Additional information
| Weight | 0,319 kg |
|---|---|
| Reference number | 1518205, 8285376000, A0007602357, A0007602857, 8010000181MO, 0007602357, 24424493, 42546, 5006035651, 81521706134, 261500072, 81521706134, 81521706137, 0007602357, 24424493, 42546, 5006035651, 0007602357, A0007602357, 0007601657, 0007602857, A0007602857, 24424493, 42546, 5006035651, 81521706134, 81521706134, 13C0056070AB, 2401174125, 24424493, 0007602357, 42546, 5006035651, 81521706134 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.18452 |
| Comments | Electircal |
| Distance between holes | 1.42×1.42 in |
| Max. operating pressure | 145.0 psi |
| Mounting | 2 x M6 |
| Nominal diameter | 3.0 mm |
| Port thread 1 | M12 x 1.5 |
| Port thread 2 | M12 x 1.5 |
| Port thread 3 | M12 x 1.5 |
| Port thread 4 | M12 x 1.5 |
| Rated current | 10 A |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | 4/2 |
| Version | Normally closed |
| Voltage | 250 V |
| Size (mm x mm x mm) | 61 x 55 x 55 |
| UPC | 193133366171 |
| Weight (kg) | 0.319 |
| Weight (lb) | 0.70327 |
| GTIN | 04057875295198 |
| Brand | WABCO |
