Additional information
| Weight | 1,339 kg |
|---|---|
| Reference number | 1518526, A0007602778, 3356151004, 5010104310, 0300637800, 5010104310, 3356151004, 5001841169, 88749206003, 0007602778, 81521606104, 0007602778, A0007602778, 81521606104, 240615900, 88749206003, 5010104310, 637212720, 60006509, 56200005 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.83232 |
| Comments | ETS |
| Distance between holes | 3.15×1.08 in |
| Electrical connection | 3x 3-Pole to fit 6.3 DIN 46247 |
| Max. operating pressure | 145.0 psi |
| Mounting | 2x Ø 5.2 mm |
| Nominal diameter | 4.0 mm |
| Port thread 11 | M12 x 1.5 |
| Port thread 12 | M12 x 1.5 |
| Port thread 21 | M12 x 1.5 |
| Port thread 22 | M12 x 1.5 |
| Port thread 23 | M12 x 1.5 |
| Port thread 24 | M12 x 1.5 |
| Port thread 3 | 5324001170 |
| Port thread 4 | Quick Connection 8 x 1 |
| Protection class | IP 65 |
| Technical specification | OE specification |
| Temperature range | -25°C to +80°C |
| Type | 4/3-Way |
| Voltage | 24 V |
| GTIN | 04057875081333 |
| Size (mm x mm x mm) | 136 x 136 x 45 |
| UPC | 193133153092 |
| Weight (kg) | 1.339 |
| Weight (lb) | 2.952 |
| Rated current | 115 mA |
| Brand | WABCO |
