Additional information
| Weight | 0,443 kg |
|---|---|
| Reference number | 1337734, 0005433985, 42531617, A0005433985, 42531617, 0005433985, 1337734, 81259026185, 0005433985, A0005433985, 1337734, 42531617, 26335NY00A |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.378 |
| Cooling | Air |
| Electrical connection | Bayonet DIN 72585-A2-4.1-Sn/K1 |
| Max. operating pressure | 188.55 psi |
| Mounting | 4x Ø 6.5 mm |
| Multi Nominal diameter (From Port 1 to x) | 0.04 in |
| Protection class | IP 6K7 / IP 6K9K |
| Rated current | 320 mA |
| Stroke | 0.03 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | 3/2, 3/2 |
| Voltage | 24 V |
| GTIN | 04057875184621 |
| Size (mm x mm x mm) | 140 x 45 x 60 |
| UPC | 193133263968 |
| Weight (lb) | 0.97665 |
| Weight (kg) | 0.443 |
| Brand | WABCO |
