Additional information
| Weight | 0,159 kg |
|---|---|
| Reference number | 1506012, 82853164830, 82853074810, A0004316813, 93190988, 93190987, 81521606121, A0004300387, 0004300387, 0004316813, A0004316813, Q82853164830, 5001834959, 1170013000, 42090112 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Application | Air dryer 432 431 …/432 … |
| Calculated Volume (dm³) | 0.25704 |
| Distance between holes | 1.5×1.65 in |
| Electrical connection | M24x1 |
| Exhaust | 1.2 mm |
| Max. operating pressure | 188.55 psi |
| Mounting | 3x 6.5 mm |
| Multi Nominal diameter (From Port 1 to x) | 0.03 in |
| Port thread 1 | 0.024 in |
| Port thread 2 | 0.04 in |
| Protection class | IP 66 A / IP 68 |
| Rated current | 600 mA |
| Technical specification | OE specification |
| Temperature range | -40°C to +65°C |
| Type | Normally Closed |
| Voltage | 24 V |
| Size (mm x mm x mm) | 84 x 45 x 68 |
| UPC | 193133439127 |
| Weight (kg) | 0.159 |
| Weight (lb) | 0.35053 |
| GTIN | 7895851066243 |
| Brand | WABCO |
