Additional information
| Weight | 0,748 kg |
|---|---|
| Reference number | 04398756, 4398756, TDAS9753034410, 04784766, 04804764, 04831983, 04842612, 42007712, 42008234, 42009103, 42021855, 42085761, 4804764, 04784776, S975-303-441-0, 5026264, 5029655, 502626408, S9753034410, S975-303-441-0, 42008234 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 1.6806 |
| Cut-out pressure | 113.13 psi |
| Max. operating pressure | 362.6 psi |
| Mounting | 2x Ø 8.8 mm |
| Opening pressure | 174 psi |
| Operational range | 8.70+5.80 psi |
| Port thread 1 | M22 x 1.5 |
| Port thread 1-2 | M16 x 1.5 |
| Port thread 12 | M16 x 1.5 |
| Port thread 21 | M22 x 1.5 |
| Port thread 22 | M12 x 1.5 |
| Port thread 3 | Union Ø 0.79 in |
| Port threads | M22 x 1.5 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | With one way valve |
| GTIN | 04057875305569 |
| Size (mm x mm x mm) | 171 x 108 x 91 |
| UPC | 193133450597 |
| Weight (kg) | 0.748 |
| Weight (lb) | 1.65 |
| Version | With tire inflating valve |
| Brand | WABCO |
