Additional information
| Weight | 11,71 kg |
|---|---|
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 28.665 |
| Comments | Universal-Tristop-Zylinder needs additional accessories (Link): – |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Output force 3 | 2607.78 lbf |
| Output force M | 2765.15 lbf |
| Port thread 11 | 3/8" – NPTF |
| Port threads | 3/8'' |
| Push-rod length | 9.84 in |
| Push-rod thread | 5/8" – 18 UNF-2A |
| Release pressure | 73.97 psi |
| Return-spring force | 56.20 lbf |
| Stroke | 2.56 / 2.56 in |
| Technical specification | OE specification |
| Thread length | 9.84 in |
| Total lenght | 11.93 in |
| Type | 30/30 IBV |
| Type of operation | Cam |
| Version | Without boot |
| Yoke | Without (5/8'-18UNF-2A) |
| GTIN | 7895851073104 |
| Size (mm x mm x mm) | 210 x 650 x 210 |
| UPC | 193133358688 |
| Weight (kg) | 11.71 |
| Weight (lb) | 25.8161 |
| Temperature range | -40°C to +80°C |
| Brand | WABCO |
