Additional information
| Weight | 8,278 kg |
|---|---|
| Reference number | 1519443, GV66002590, GV66002590, 00132723 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 23.5638 |
| Comments | Universal-Tristop-Zylinder needs additional accessories (Link): 423 000 901 2 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Output force 3 | 1955.84 lbf |
| Output force M | 1686.07 lbf |
| Port thread 11 | M16 x 1.5 |
| Port thread 12 | M16 x 1.5 |
| Port threads | M16 x 1.5 . M22 x 1.5 |
| Push-rod length | 9.84 in |
| Push-rod thread | M16 x 1.5 |
| Release pressure | 73.97 psi |
| Return-spring force | 56.20 lbf |
| Stroke | 2.24 / 2.24 in |
| Temperature range | -40°C to +80°C |
| Thread length | 9.84 in |
| Total lenght | 9.92 in |
| Type | 20/24 IBV |
| Type of operation | Cam |
| Version | with boot |
| Yoke | Without |
| GTIN | 04057875285878 |
| Size (mm x mm x mm) | 570 x 212 x 195 |
| UPC | 193133356486 |
| Weight (kg) | 8.278 |
| Weight (lb) | 18.25 |
| Technical specification | OE specification |
| Brand | WABCO |
