Additional information
| Weight | 11,118 kg |
|---|---|
| Reference number | 660740, 8143104, 89199797624, 169691, 0005680011, 2089721, 1020767 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 30.5415 |
| Comments | Universal-Tristop-Zylinder needs additional accessories (Link): 423 000 901 2 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Output force 3 | 2585.30 lbf |
| Output force M | 2903.41 lbf |
| Port thread 11 | M16 x 1.5 |
| Port thread 12 | M16 x 1.5 |
| Port threads | M16 x 1.5 . M22 x 1.5 |
| Push-rod length | 9.92 in |
| Push-rod thread | M16 x 1.5 |
| Release pressure | 75.42 psi |
| Return-spring force | 62.95 lbf |
| Stroke | 2.56 / 2.56 in |
| Temperature range | -40°C to +80°C |
| Thread length | 9.84 in |
| Total lenght | 11.22 in |
| Type | 30/30 IBV |
| Type of operation | Cam |
| Version | With boot |
| Yoke | Without |
| GTIN | 7895851073098 |
| Size (mm x mm x mm) | 617 x 225 x 220 |
| UPC | 193133448211 |
| Weight (kg) | 11.118 |
| Weight (lb) | 24.511 |
| Technical specification | OE specification |
| Brand | WABCO |
