Additional information
| Weight | 11,26 kg |
|---|---|
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 33.856 |
| Comments | Universal-Tristop-Zylinder needs additional accessories (Link): 423 000 901 2 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Output force 3 | 2585.30 lbf |
| Output force M | 2405.46 lbf |
| Port thread 11 | M16 x 1.5 |
| Port threads | M16 x 1.5 . M22 x 1.5 |
| Push-rod length | 9.84 in |
| Push-rod thread | M16 x 1.5 |
| Release pressure | 73.97 psi |
| Return-spring force | 56.20 lbf |
| Stroke | 2.56 / 2.56 in |
| Technical specification | OE specification |
| Thread length | 9.84 in |
| Total lenght | 11.22 in |
| Type | 27/30 IBV |
| Type of operation | Cam |
| Version | Without boot |
| Yoke | Without (M 16×1.5) |
| GTIN | 04057875287872 |
| Size (mm x mm x mm) | 230 x 640 x 230 |
| UPC | 193133359265 |
| Weight (kg) | 11.26 |
| Weight (lb) | 24.824 |
| Temperature range | -40°C to +80°C |
| Brand | WABCO |
