Additional information
| Weight | 20,85 kg |
|---|---|
| Reference number | 4571306915, A4571306915, 4571304715 |
| Brand | ZF REMAN – WABCO |
| Part type | Remanufactured |
| Product category | Device |
| Calculated Volume (dm³) | 15.19 |
| Cooling | Water |
| Crankshaft thread | M20 x 1.5 |
| Important information | When replacing this compressor a new flange gasket is required. Flange gasket 9121101404 to be bought separately |
| Lubrication | Lubrication supplied from engine |
| Max. operating pressure | 181.3 psi |
| Mounting | Mounting Flange |
| Operating speed | 3000 (1/min) |
| Piston diameter | 3.35 in |
| Piston stroke | 2.20 in |
| Port thread 0 | M30 x 1.5 |
| Port thread 2 | M26 x 1.5 |
| Port thread 21 | M26 x 1.5 (closed) |
| Port thread 22 | M26 x 1.5 |
| Port thread 4 | M12 x 1.5 |
| Port thread 8.1 | Ø 0.16 in |
| Port thread 9 | M12 x 1.5 |
| Port thread 9.1 | M16 x 1.5 |
| Port thread 9.2 | M16 x 1.5 |
| Swept volume (cm³) | 636 cm<sup>3</sup> |
| Technical specification | OE specification |
| Type | Twin Cylinder |
| GTIN | 04057875343707 |
| Size (mm x mm x mm) | 350 x 280 x 155 |
| UPC | 193133412847 |
| Weight (kg) | 20.85 |
| Weight (lb) | 45.97 |
| Port thread 8.2 | Ø 0.62 in |
| Brand | WABCO |
