Additional information
| Weight | 11,65 kg |
|---|---|
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 2.22 in |
| Bolt threads | 2 x M16 x 1.5 |
| Calculated Volume (dm³) | 0 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Port thread 11 | 3/8" – 18 NPTF |
| Push-rod length | 6.85 in |
| Push-rod thread | 5/8'' – 18 UNF |
| Release pressure | 73.97 psi |
| Return-spring force | 56.20 lbf |
| Stroke | 2.52 / 2.52 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 11.34 in |
| Type | 24/30 |
| Type of operation | Cam |
| GTIN | 7895851034259 |
| UPC | 193133347743 |
| Weight (kg) | 0 |
| Weight (lb) | 0 |
| Version | with boot |
| Brand | WABCO |
