Additional information
| Weight | 8,4 kg |
|---|---|
| Reference number | 70330088 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | 5/8" – 18 – UNF-2A |
| Calculated Volume (dm³) | 15.2 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Output force 3 | 1955.84 lbf |
| Output force M | 1573.66 lbf |
| Port thread 11 | M16 x 1.5 |
| Port threads | M16 x 1.5 |
| Push-rod length | 1.57 in |
| Push-rod thread | 5/8" – 18 UNF-2A |
| Release pressure | 71.07 psi |
| Return-spring force | 49.46 lbf |
| Stroke | 2.56 / 2.56 in |
| Technical specification | OE specification |
| Temperature range | -45°C to +80°C |
| Total lenght | 10.83 in |
| Type | 20/24 |
| Type of operation | Cam |
| Version | Without boot |
| Yoke | Without (5/8'-18UNF-2A) |
| GTIN | 04057875288176 |
| Size (mm x mm x mm) | 400 x 200 x 190 |
| Weight (kg) | 8.4 |
| Thread length | 1.38 in |
| Brand | WABCO |
