Additional information
| Weight | 8,4 kg |
|---|---|
| Reference number | 3986699, 21011721 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.52 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 0 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Port thread 11 | M16 x 1.5 JED – 464 |
| Push-rod length | 2.28 in |
| Push-rod thread | M16 x 1.5 |
| Release pressure | 71.07 psi |
| Return-spring force | 44.96 lbf |
| Stroke | 2.56 / 2.56 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 10.67 in |
| Type | 24/24 |
| Type of operation | Cam |
| Yoke | Screwed |
| GTIN | 04057875286073 |
| Weight (kg) | 0 |
| Version | Without boot |
| Brand | WABCO |
