Additional information
| Weight | 9,85 kg |
|---|---|
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.30 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 17.2225 |
| Clevis pin | 0.55 in |
| Comments | With VOSS 232 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 145.04 / 116.03 psi |
| Opposite | 925 481 021 0 |
| Output force M | 1955.84 lbf |
| Port thread 11 | M22 x 1.5 JED – 388 |
| Port thread 12 | M22 x 1.5 JED – 388 |
| Port threads | M22 x 1.5 |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Release pressure | 73.97 psi |
| Return-spring force | 56.20 lbf |
| Technical specification | OE specification |
| Temperature range | -40°F to +176°F |
| Total lenght | 10.24 in |
| Type | 24/24 |
| Type of operation | Disc |
| Version | With boot |
| Yoke | Welded |
| GTIN | 04057875282914 |
| Size (mm x mm x mm) | 420 x 203 x 202 |
| Weight (kg) | 9.85 |
| Stroke | 2.24 / 2.24 in |
| Brand | WABCO |
