Additional information
| Weight | 7,876 kg |
|---|---|
| Reference number | 1505440, A0184205518, 002773, GB54100010, GB54100010, VF23919270, 0184205518, A0184205518, 1456904, 17501, 499026, 1505440, 5010422755, 1935449, WA9254601000 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 14.37 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Opposite | 925 460 101 0 |
| Output force M | 1575.91 lbf |
| Port thread 11 | M16 x 1.5 |
| Port thread 12 | M16 x 1.5 |
| Port threads | M16 x 1.5 |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Release pressure | 73.97 psi |
| Return-spring force | 49.46 lbf |
| Stroke | 2.52 / 2.52 in |
| Technical specification | OE specification |
| Total lenght | 10.20 in |
| Type | 20/24 |
| Type of operation | Disc |
| GTIN | 04057875281467 |
| Size (mm x mm x mm) | 384 x 189 x 198 |
| UPC | 193133448044 |
| Weight (kg) | 7.876 |
| Weight (lb) | 17.364 |
| Temperature range | -40°C to +80°C |
| Brand | WABCO |
