Additional information
| Weight | 7,863 kg |
|---|---|
| Reference number | 1519191, 344149, 1235495, 4454105100, 2090328, 1125682 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 14.3354 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Output force M | 2234.60 lbf |
| Port thread 11 | M16 x 1.5 |
| Port thread 12 | M16 x 1.5 |
| Port threads | M16 x 1.5 |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Release pressure | 73.97 psi |
| Return-spring force | 49.46 lbf |
| Stroke | 2.24 / 2.24 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | 20/24 |
| Type of operation | Disc |
| GTIN | 04057875281412 |
| Size (mm x mm x mm) | 377 x 195 x 195 |
| UPC | 193133448037 |
| Weight (kg) | 7.863 |
| Weight (lb) | 17.335 |
| Total lenght | 9.92 in |
| Brand | WABCO |
