Additional information
| Weight | 9,2 kg |
|---|---|
| Reference number | 68323841, 10700275 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.50 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 22.176 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 145.04 / 123.28 psi |
| Output force M | 2248.09 lbf |
| Port thread 11 | M22 x 1.5 |
| Port threads | M22 x 1.5 |
| Push-rod length | 0.79 in |
| Push-rod thread | Ball R8 |
| Release pressure | 73.97 psi |
| Return-spring force | 44.96 lbf |
| Stroke | 2.95 / 2.95 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 11.81 in |
| Type of operation | Disc |
| GTIN | 04057875281573 |
| Size (mm x mm x mm) | 210 x 480 x 220 |
| UPC | 193133448068 |
| Weight (kg) | 9.2 |
| Weight (lb) | 20.283 |
| Type | 20/24 |
| Brand | WABCO |
