Additional information
| Weight | 9,044 kg |
|---|---|
| Reference number | 1501927, 0194205318, 0154203318, 0154204118, 0194206318, A0194205318, A0194295318, A0194206318, 1501927, 1935463 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 15.3685 |
| Comments | With VOSS 232 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Opposite | 925 484 011 0 |
| Output force M | 1863.67 lbf |
| Port thread 11 | M22 x 1.5 JED – 388 |
| Port thread 12 | M22 x 1.5 JED – 388 |
| Port threads | M22 x 1.5 |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Release pressure | 88.47 psi |
| Return-spring force | 49.46 lbf |
| Stroke | 2.52 / 2.52 in |
| Temperature range | -40°C to +80°C |
| Total lenght | 10.91 in |
| Type | 16/24 |
| Type of operation | Disc |
| GTIN | 04057875284239 |
| Size (mm x mm x mm) | 417 x 189 x 195 |
| UPC | 193133355861 |
| Weight (kg) | 9.044 |
| Weight (lb) | 19.939 |
| Technical specification | OE specification |
| Brand | WABCO |
