Additional information
| Weight | 6,9 kg |
|---|---|
| Reference number | 0884496, 10295241, 0214206118, 4454104600 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 12.987 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Output force M | 1674.83 lbf |
| Port thread 11 | M16 x 1.5 |
| Port threads | M16 x 1.5 |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Release pressure | 73.97 psi |
| Return-spring force | 49.46 lbf |
| Stroke | 2.24 / 2.24 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 9.96 in |
| Type of operation | Disc |
| GTIN | 04057875282181 |
| Size (mm x mm x mm) | 185 x 390 x 180 |
| Weight (kg) | 6.9 |
| Type | 16/16 IBV |
| Brand | WABCO |
