Additional information
| Weight | 7,025 kg |
|---|---|
| Reference number | 661068, 1506402, 7042769, A0174208918, 007914, M076162, A3A827202, GV66002810, GV66002810, 9254644510, 2002002, VS70000054, 58128680, 5812868, 336681, 0174208918, A0174208918, 1815492, 1506402, 2090334, 1020763, 21151105216 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 12.0972 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Opposite | 925 464 450 0 |
| Output force M | 1382.58 lbf |
| Port thread 11 | M16 x 1.5 |
| Port thread 12 | M16 x 1.5 |
| Port threads | M16 x 1.5 |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Release pressure | 73.97 psi |
| Return-spring force | 49.46 lbf |
| Stroke | 2.24 / 2.24 in |
| Technical specification | OE specification |
| Total lenght | 9.96 in |
| Type | 16/16 |
| Type of operation | Disc |
| GTIN | 04057875282198 |
| Size (mm x mm x mm) | 382 x 174 x 182 |
| UPC | 193133353614 |
| Weight (kg) | 7.025 |
| Weight (lb) | 15.487 |
| Temperature range | -40°C to +80°C |
| Brand | WABCO |
