Additional information
| Weight | 7,026 kg |
|---|---|
| Reference number | 661067, 1505447, 7042768, A0174208818, 13845, 007913, M076154, A3A827201, GV66002800, GV66002800, 9254644500, 2002001, VS70000053, 58128670, 5812867, 334655, 336679, 0174208818, A0174208818, 1815474, 1505447, 2090333, 1020764 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 11.5516 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Opposite | 925 464 451 0 |
| Output force M | 1382.58 lbf |
| Port thread 11 | M16 x 1.5 |
| Port thread 12 | M16 x 1.5 |
| Port threads | M16 x 1.5 |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Release pressure | 73.97 psi |
| Return-spring force | 49.46 lbf |
| Stroke | 2.24 / 2.24 in |
| Technical specification | OE specification |
| Total lenght | 9.96 in |
| Type | 16/16 |
| Type of operation | Disc |
| GTIN | 04057875282174 |
| Size (mm x mm x mm) | 349 x 177 x 187 |
| UPC | 193133353638 |
| Weight (kg) | 7.026 |
| Weight (lb) | 15.49 |
| Temperature range | -40°C to +80°C |
| Brand | WABCO |
