Additional information
| Weight | 7,001 kg |
|---|---|
| Reference number | 1505437, 81504106575, 81504106577, 81504106579, 81504106641, 81504109575, 81504106575, 1505437 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.50 in |
| Bolt threads | 2 x M16 x 1.5 |
| Calculated Volume (dm³) | 13.1115 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 145.04 / 123.28 psi |
| Opposite | 925 426 201 0 |
| Output force 3 | 1663.59 lbf |
| Output force M | 1393.82 lbf |
| Port thread 11 | M22 x 1.5 JED – 388 |
| Port thread 12 | M22 x 1.5 JED – 388 |
| Port threads | M16 x 1.5 |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Release pressure | 73.97 psi |
| Return-spring force | 33.72 lbf |
| Stroke | 2.24 / 2.24 in |
| Temperature range | -40°C to +80°C |
| Total lenght | 9.92 in |
| Type | 14/16 |
| Type of operation | Disc |
| GTIN | 04057875280071 |
| Size (mm x mm x mm) | 379 x 187 x 185 |
| UPC | 193133351443 |
| Weight (kg) | 7.001 |
| Weight (lb) | 15.435 |
| Technical specification | OE specification |
| Brand | WABCO |
