Additional information
| Weight | 6,901 kg |
|---|---|
| Reference number | 81504106642, 81504106644, 81504106646, 81504106663, 81504109644, 81504106644, 5010422316 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.50 in |
| Bolt threads | 2 x M16 x 1.5 |
| Calculated Volume (dm³) | 12.825 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 145.04 / 123.28 psi |
| Opposite | 925 426 100 0 |
| Output force 3 | 1843.43 lbf |
| Output force M | 1191.49 lbf |
| Port thread 11 | M22 x 1.5 JED – 388 |
| Port threads | M22 x 1.5 |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Release pressure | 79.77 psi |
| Return-spring force | 33.72 lbf |
| Stroke | 2.52 / 2.52 in |
| Technical specification | OE specification |
| Total lenght | 9.92 in |
| Type | 12/16 |
| Type of operation | Disc |
| GTIN | 04057875280040 |
| Size (mm x mm x mm) | 375 x 190 x 180 |
| UPC | 193133351412 |
| Weight (kg) | 6.901 |
| Weight (lb) | 15.214 |
| Temperature range | -40°C to +80°C |
| Brand | WABCO |
