Additional information
| Weight | 11,2 kg |
|---|---|
| Reference number | 1519166, A0134207618, 0134207618, A0134207618, 5021170328 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.30 in |
| Bolt threads | 2 x M16 x 1.5 |
| Calculated Volume (dm³) | 27.456 |
| Clevis pin | 0.55 in |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Opposite | 925 422 433 0 |
| Output force 3 | 2922.52 lbf |
| Output force M | 2517.86 lbf |
| Port thread 11 | M16 x 1.5 |
| Port threads | M22 x 1.5 |
| Push-rod length | 3.03 in |
| Release pressure | 84.12 psi |
| Return-spring force | 56.20 lbf |
| Stroke | 2.56 / 2.56 in |
| Technical specification | OE specification |
| Total lenght | 11.93 in |
| Type | 30/30 |
| Type of operation | Cam |
| Version | with boot |
| Yoke | Welded |
| GTIN | 7895851078550 |
| Size (mm x mm x mm) | 240 x 520 x 220 |
| UPC | 193133351108 |
| Weight (kg) | 11.2 |
| Weight (lb) | 24.6917 |
| Temperature range | -40°C to +80°C |
| Brand | WABCO |
