Additional information
| Weight | 10,817 kg |
|---|---|
| Reference number | 1602677 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.30 in |
| Bolt threads | 2 x M16 x 1.5 |
| Calculated Volume (dm³) | 19.5048 |
| Clevis pin | 0.55 in |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Opposite | 925 422 150 0 |
| Output force 3 | 2529.10 lbf |
| Output force M | 2472.90 lbf |
| Port thread 11 | M22 x 1.5 JED – 388 |
| Port threads | M22 x 1.5 |
| Push-rod length | 1.97 in |
| Release pressure | 73.97 psi |
| Return-spring force | 56.20 lbf |
| Stroke | 2.56 / 2.56 in |
| Technical specification | OE specification |
| Total lenght | 11.42 in |
| Type | 30/30 |
| Type of operation | Cam |
| Version | Without boot |
| Yoke | Welded |
| GTIN | 04057875279532 |
| Size (mm x mm x mm) | 432 x 210 x 215 |
| UPC | 193133351016 |
| Weight (kg) | 10.817 |
| Weight (lb) | 23.8474 |
| Temperature range | -40°C to +80°C |
| Brand | WABCO |
