Additional information
| Weight | 10,032 kg |
|---|---|
| Reference number | 1446056, 1367493 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 18.346 |
| Clevis pin | 0.63 in |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.9/123.3 psi |
| Output force 3 | 1978.32 lbf |
| Output force M | 2382.98 lbf |
| Port thread 11 | M16 x 1.5 JED – 152 |
| Port thread 12 | M12 x 1.5 JED – 152 |
| Port threads | M16 x 1.5 |
| Push-rod length | 2.76 in |
| Push-rod thread | M16 x 1.5 |
| Release pressure | 71.07 psi |
| Return-spring force | 98.92 lbf |
| Stroke | 2.56 / 2.56 in |
| Temperature range | -40°C to +80°C |
| Total lenght | 11.30 in |
| Type | 30/24 |
| Type of operation | Cam |
| Version | Without boot |
| Yoke | Screwed: 895 802 090 4 |
| GTIN | 7895851032736 |
| Size (mm x mm x mm) | 416 x 210 x 210 |
| UPC | 193133352617 |
| Weight (kg) | 10.032 |
| Weight (lb) | 22.1167 |
| Technical specification | OE specification |
| Brand | WABCO |
