Additional information
| Weight | 9,82 kg |
|---|---|
| Reference number | 1325349, 7132159, 051019, 51019, C3276-6438-0A, C3276-6438-0 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 27.72 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Port thread 11 | M16 x 1.5 |
| Push-rod length | 7.87 in |
| Push-rod thread | M16 x 1.5 |
| Release pressure | 71.07 psi |
| Return-spring force | 50.58 lbf |
| Stroke | 2.56 / 2.56 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 11.30 in |
| Type | 30/24 |
| Type of operation | Cam |
| Yoke | Without |
| GTIN | 04057875287209 |
| Size (mm x mm x mm) | 600 x 220 x 210 |
| UPC | 193133358633 |
| Weight (kg) | 9.82 |
| Weight (lb) | 21.649 |
| Version | Without boot |
| Brand | WABCO |
