Additional information
| Weight | 9,41 kg |
|---|---|
| Reference number | 1079945, 20466200, 20533210 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.38 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 26.198 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 145.04 / 123.28 psi |
| Output force 3 | 1955.84 lbf |
| Output force M | 2225.61 lbf |
| Port thread 11 | M16 x 1.5 |
| Port thread 12 | M16 x 1.5 |
| Port threads | M16 x 1.5 |
| Push-rod length | 8.66 in |
| Push-rod thread | M16 x 1.5 |
| Release pressure | 71.07 psi |
| Return-spring force | 56.20 lbf |
| Stroke | 2.56 / 2.56 in |
| Technical specification | OE specification |
| Thread length | 3.54 in |
| Total lenght | 10.59 in |
| Type | 27/24 |
| Type of operation | Cam |
| Version | Without boot |
| Yoke | No |
| GTIN | 7895851077744 |
| Size (mm x mm x mm) | 560 x 207 x 226 |
| UPC | 193133352853 |
| Weight (kg) | 9.41 |
| Weight (lb) | 20.745 |
| Temperature range | -40°C to +80°C |
| Brand | WABCO |
