Additional information
| Weight | 10,63 kg |
|---|---|
| Reference number | 1523180, 1446053 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.52 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 21.17 |
| Clevis pin | 0.63 in |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 152.29 / 123.28 psi |
| Opposite | 925 431 423 0 |
| Output force 3 | 2427.94 lbf |
| Output force M | 1708.55 lbf |
| Port thread 11 | M16 x 1.5 JED – 152 |
| Port thread 12 | M12 x 1.5 JED – 152 |
| Port threads | M16 x 1.5 |
| Push-rod length | 2.76 in |
| Push-rod thread | M16 x 1.5 |
| Release pressure | 71.07 psi |
| Return-spring force | 56.20 lbf |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 11.38 in |
| Type | 24/30 |
| Type of operation | Cam |
| Version | Without boot |
| Yoke | Screwed: 895 802 090 4 |
| GTIN | 7895851032750 |
| Size (mm x mm x mm) | 480 x 210 x 210 |
| UPC | 193133352204 |
| Weight (kg) | 10.63 |
| Weight (lb) | 23.44 |
| Stroke | 2.56 / 2.56 in |
| Brand | WABCO |
