Additional information
| Weight | 11,039 kg |
|---|---|
| Reference number | 20533205, 20533205, 1629040, 20399761, 20438488, 20466208, 3987106 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.52 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 35.782 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Output force 3 | 2585.30 lbf |
| Output force M | 1865.91 lbf |
| Port thread 11 | M16 x 1.5 JED – 464-0 |
| Port threads | M16 x 1.5 |
| Push-rod length | 2.28 in |
| Push-rod thread | M16 x 1.5 |
| Release pressure | 76.87 psi |
| Return-spring force | 44.96 lbf |
| Stroke | 2.56 / 2.56 in |
| Technical specification | OE specification |
| Temperature range | -45°C to +80°C |
| Total lenght | 10.71 in |
| Type | 24/30 |
| Type of operation | Cam |
| Version | Without boot |
| Yoke | Without (M 16×1.5) |
| GTIN | 7895851027442 |
| Size (mm x mm x mm) | 590 x 266 x 228 |
| UPC | 193133357612 |
| Weight (kg) | 11.039 |
| Weight (lb) | 24.3368 |
| Thread length | 1.97 in |
| Brand | WABCO |
