Additional information
| Weight | 10,46 kg |
|---|---|
| Reference number | 20533203, 1629512, 20438489, 3987107 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.52 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 20.577 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Output force 3 | 2585.30 lbf |
| Output force M | 1865.91 lbf |
| Port thread 11 | M16 x 1.5 JED – 464-0 |
| Port threads | M16 x 1.5 |
| Push-rod length | 8.66 in |
| Push-rod thread | M16 x 1.5 |
| Release pressure | 76.87 psi |
| Return-spring force | 44.96 lbf |
| Stroke | 2.56 / 2.56 in |
| Technical specification | OE specification |
| Temperature range | -45°C to +80°C |
| Total lenght | 10.71 in |
| Type | 24/30 |
| Type of operation | Cam |
| Version | Without boot |
| Yoke | Without (M 16×1.5) |
| GTIN | 04057875286462 |
| Size (mm x mm x mm) | 190 x 190 x 570 |
| UPC | 193133357667 |
| Weight (kg) | 10.46 |
| Weight (lb) | 23.0603 |
| Thread length | 1.97 in |
| Brand | WABCO |
