Additional information
| Weight | 10,5 kg |
|---|---|
| Reference number | 20986736, 20721062, 2098673 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | 2 x M16 x 1.5 |
| Calculated Volume (dm³) | 0.00000099999999747524 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 152.29 / 123.28 psi |
| Output force 3 | 1708.55 lbf |
| Output force m | 7600 N |
| Port thread 11 | M16 x 1.5 |
| Push-rod length | 1.5 in |
| Push-rod thread | M16 x 1.5 |
| Release pressure | 84.12 psi |
| Return-spring force | 49.46 lbf |
| Stroke | 2.56 / 2.56 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 11.38 in |
| Type of operation | Cam |
| Version | Without boot |
| Yoke | screwed |
| GTIN | 7895851054462 |
| Size (mm x mm x mm) | 1 x 1 x 1 |
| UPC | 193133350323 |
| Weight (kg) | 10.5 |
| Weight (lb) | 23.1485 |
| Type | 24/30 |
| Brand | WABCO |
